10A C14 C15 LSZH Power Cords - BLACK

10A C14 C15 LSZH Power Cords - BLACK

IEC 60320 C14 to C15 Power Cables utilizing LOW SMOKE ZERO HALOGEN cordage (BSI, HAR, ROHS, IEC, HD21.14, BS EN 50525-3-11). For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. LSZH, LS0H, LSOH, LSFH, 0HLS, OHLS.

For help finding a product or for product additional product information , call us at (860) 763-2100 or email sales@worldcordsets.com


Part Number
Length
Current (Amps)
Voltage (Volts)
Connector (Female)
Plug (Male)
Availability
1+
10+
100+
  • 1 Foot
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
1 Foot
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 1.5 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
1.5 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 2 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
2 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 2.5 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
2.5 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 3 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
3 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 1.0 meter
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
1.0 meter
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 3.5 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
3.5 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 4 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
4 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 4.5 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
4.5 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 5 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
5 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 6 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
6 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 2.0 meters
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
2.0 meters
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 7 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
7 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 8 Feet , 2.5 meters
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
8 Feet , 2.5 meters
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 9 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
9 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 10 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
10 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 3.5 meters
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
3.5 meters
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 12 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
12 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 4.0 meters
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
4.0 meters
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :

  • 15 Feet
  • 10 Amps
  • 250 volts
  • IEC 60320 C15 Photo of IEC 60320 C15
  • IEC 60320 C14 Photo of IEC 60320 C14
15 Feet
10 Amps
250 volts
IEC 60320 C15
IEC 60320 C14

1+ :

10+ :

100+ :



Specifications of LSZH C14 C15 Power Cords

Current (Amps)
Voltage (Volts)
Plug (Male)
Cordage
Certifications
Country of Origin
Color
Connector (Female)

General Information about C14 C15 LSZH Cord Sets

Our C14 to C15 LSZH Cord Sets utilize Low Smoke Zero Halogen 18/3 cordage. These are typically used in locations where damage from smoke could cause serious harm to humans, or, damage to equipment. Our C14 to C15 LSZH 18/3 Cord Sets are rated for 10amps and 250V. However, in the united states these are often used in 125V circuits and will work perfectly for this application.

IEC 60320 C14 PLUG (MALE)

IEC 60320 C14 PLUG (MALE)

General Information:

The IEC 60320 C14 is a grounded 3 Wire Plug rated up to 250V and 15 Amps. The C14 plug is one of the most commonly used plugs in the data center industry, especially the Inlet version, which is found on the vast majority of Information Technology devices that are produced today. The IEC 60320 C14 is typically used with either 18awg SVT, 18awg SJT(OW), 16awg SJT(OW) or 14awg SJT(OW). The types of cordages used will change the rating of the overall cord set. This plug is very common in consumer, commercial and industrial applications which can create many different names for this plug across different industries like the computer plug, IEC plug, and more generalized names. Some also refer to this as the iec C13 plug, or the c13 power plug because of the C13 connector that it mates with.

What does the IEC 60320 C14 plug into?




IEC 60320 C13 Connector
IEC 60320 C13 Outlet
The IEC 60320 C14 plug is designed to connect to the IEC 320 C13 connector and the outlet. The connector is found on a variety of 10-15A power cords, while the outlet is located on a variety of power supplies. The outlet is most commonly found on Power Distribution Units found in office, commercial, or data center settings as well as Power Adapter bricks.

IEC 60320 C15 CONNECTOR (FEMALE)

IEC 60320 C15 CONNECTOR (FEMALE)

General Information:

The IEC 60320 C15 is a grounded 3 Wire connector rated up to 250V & 10 Amps Internationally and 125V/250V & 15 Amps in North America. The C15 mates with a C16 inlet and can also be down graded to a C14 Inlet. C14 Inlet and is commonly used in IT Installations providing power from a PDU to a server, router, switch or other computing device. The C15 is a HIGH TEMPERATURE connector rated up to 120°C, unlike the 70°C rating of the C13. The C15 is commonly used in in electric kettles and other household appliances that involve higher temperatures than a normal C13 is made to withstand. There is a dimple located below the ground pin to ensure that the standard C13 connector cannot be plugged into the C16 Inlet which is used on high temperature applications. This design is utilized to allow this C15 connector to be used on both high temperature applications and standard applications, as to not limit the user. The C15 connector is commonly used with 18awg SJT(OW), 16awg SJT(OW), and 14awg SJT(OW).

What does the IEC 60320 C15 Connect to?





IEC 60320 C14 Inlet
IEC 60320 C16 High Temperature InletThe IEC 60320 type C15 connector is designed to plug into the high temperature rated IEC 320 C16 Inlet. This inlet is commonly found on high performance IT Equipment that reaches heats that exceed the rating of the standard IEC C13 connector. This inlet is designed to reach temperatures up to 120*C. The C15 can also be plugged into a standard non-high temp application C14 Inlet, which is located on a wide variety of IT Equipment like computer monitors and switches.


18awg-3C LSZH Cordage

18awg-3C LSZH Cordage

Why use LSZH cordage?

Standard power cable jackets are made from a PVC compound containing Chlorine (part of the Halogen Group), which, when burned release a toxic gas that can cause serious damage to humans and electrical equipment. This raises concerns in applications that have dense PVC cabling where electrical equipment or people are present. Low Smoke Zero Halogen products solve this by removing halogens (up to required standards) from the material used to manufacture LSZH products.  You can find the amount of halogen contained in typical LSZH Cable in Table 2 below.


PolymerHalogen Content % by Weight
PU (polyurethane)
<.02
EPR (Ethylene propylene rubber)<.02
PE (polyethylene)<.02
XLP (Cross-Linked Polyethylene)
<.02
CSPE (chlorosulfonated polyethylene)

13-26
CPE (chlorinated polyethylene)

14-28
PVC (polyvinyl chloride)22-29
FEP (fluorinated ethylene propylene)

62-78


What are the standard applications of LSZH?

Low Smoke Zero Halogen cabling is usually used in regulated industries such as government. New data centers are sometimes choosing to use LSZH cabling to help protect data center facilities from the harmful smoke in case of fire. Because data centers utilize large ventilation systems, even a small amount of smoke in a small area can quickly be distributed accidentally throughout the entire building through the ventilation systems.

Low Smoke Zero Halogen - General Information

Why Low Smoke Zero Halogen?


Standard power cable jackets are made from a PVC compound containing Chlorine (part of the Halogen Group), which, when burned release a toxic gas that can cause serious damage to humans and electrical equipment. This raises concerns in applications that have dense PVC cabling where electrical equipment or people are present. Low Smoke Zero Halogen, also known as Low Smoke Free of Halogen or (LSZH, LSOH, LS0H, OHLS) refers to the cable jacketing which is composed of thermoplastics/thermoset compounds that release limited smoke and no halogens when exposed to high heat/fire. This cordage was initially invented to solve two main problems: reduce smoke/improve visibility in an emergency fire escape situation and reduce toxins being released in such a fire that could harm victims exposed. This cordage is generally used where there is limited ventilation or where set standards require such health/safety measures.  You can find the amount of halogen contained in typical LSZH Cable in Table 2 below.


Common Abbreviations and Terms for Low Smoke Zero Halogen


TERM/ABBREVIATION
MEANING
LSZH
Low Smoke Zero Halogen
LSF
Low Smoke/Fume
LS0H
Low Smoke Zero Halogen
LSHF
Low Smoke Halogen Free
LSNH
Low Smoke No Halogen
NHFR
NonHalogen Flame Retardant
HFFR
Halogen Free Flame Retardant
FRNC
Fire Retardant, Non-Corrosive
LS
Low/Limited Smoke
ST
Smoke Test
FRLS
Fire Resistant, Low Smoke
RE
Reduced Emissions
LC
Low Corrosivity
LH
Low Halogen

Table 1: Low Smoke Zero Halogen Terms and Abbreviations



Halogen Content in Standard Wire & Cable Polymers


Using the table below, you can see that standard PVC cables contain vastly greater amounts halogen contents that any of the LSZH polymers.


PolymerHalogen Content % by Weight
PU (polyurethane)
<.02
EPR (Ethylene propylene rubber)<.02
PE (polyethylene)<.02
XLP (Cross-Linked Polyethylene)
<.02
CSPE (chlorosulfonated polyethylene)

13-26
CPE (chlorinated polyethylene)

14-28
PVC (polyvinyl chloride)22-29
FEP (fluorinated ethylene propylene)

62-78

Table 2: Halogen Content in Typical Wire & Cable Polymers


When should I use LSZH cabling?


Low Smoke Zero Halogen cabling is usually used in regulated industries such as government. New data centers are sometimes choosing to use LSZH cabling to help protect data center facilities from the harmful smoke in case of fire. Because data centers utilize large ventilation systems, even a small amount of smoke in a small area can quickly be distributed accidentally throughout the entire building through the ventilation systems. A side note is the National Electrical Code requires cables used in plenum spaces to be Low Smoke Emitting, which is another common usage of this cordage. Refer to the National Electrical Code(NEC), or the National Fire Protection Agency(NFPA) to determine if LSZH cordage is right for you.

White Label Shipping

White Label Shipping

Are you a reseller looking for Blind or White Label Drop Shipping? We offer both! During checkout simply select "Blind Shipping", then either upload your own packing slip, or, upload your logo and part numbers into ours. You will receive automated tracking emails as soon as your order has been packed so you can keep your customer up to date in realtime. Blind drop shipping has never been easier. Contact us today!

Manufactured Under ISO: 9001

Manufactured Under ISO: 9001

Our power cord sets are manufactured under an ISO 9001 quality management system to ensure that you get the same outstanding quality with on every order you place.
All of our NorthAmerican use Power Cord Sets are UL listed under E503529. This means that you can be sure that all of our power cord sets are of the highest quality and are certified for use in the United States.

UL Listed : E503526

UL Listed : E503526

World Cord Sets strives to deliver the best quality products for the lowest cost, to show our commitment to quality and our understanding of customers expectation for consistence of quality we obtained the UL certification. All of our North American use Power Cord Sets are UL listed under E503529. This means that you can be sure that all of our power cord sets are of the highest quality and are certified for use in the United States.

Lifetime Warranty

Lifetime Warranty

Why do we offer a lifetime warranty?

We offer a lifetime warranty because we know that it won't have to be used. Our products are manufactured using only the highest quality components, and, undergo rigorous quality assurance inspections and testing to ensure all of our products meet our exacting standards. Our lifetime warranty gives you peace of mind that your purchase is 100% guaranteed to work.


What does the warranty cover?

All cords, cables, patch panels, and adapters sold on this website in original unmodified condition are covered under this warranty. Warranty does not cover damage caused by misuse.


How does the warranty work?

To use the lifetime warranty, simply request an RMA and send your defective material back to us and we will either repair or replace the goods and return them back to you in working condition.
