NEMA 6-20P to IEC 60320 C13 15A 250V Adapter Power Cords - BLACK

NEMA 6-20P to C13 PDU Power Supply Cord | World Cord Sets, Inc.

NEMA 6-20P to C13 15A 250V Power Cords - BLACK

The NEMA 6-20P is a 3 Wire grounded plug featuring two blades and one ground pin rated up to 250V AC and 20 Amps. The NEMA 6-20P has one horizontal blade and one vertical blade and mates with a 6-20R Outlet.

The IEC 60320 C13 is a grounded 3 Wire connector rated up to 250V and 15 Amps. The C13 mates with a C14 inlet, and is commonly used in a jumper cable scenario in IT Installations providing power from a PDU to a server, router, switch or other computing device. Most people know the C13 PDU power cord as 'the thing that plugs into my computer' because it is the standard connector used to power most desktop computers.

For help finding a product or for product additional product information , call us at (860) 763-2100 or email sales@worldcordsets.com


Part Number
Length
Current (Amps)
Voltage (Volts)
Connector (Female)
Plug (Male)
Availability
1+
10+
100+
  • 1 Foot
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
1 Foot
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 2 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
2 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 3 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
3 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 4 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
4 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 5 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
5 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 6 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
6 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 2.0 meters
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
2.0 meters
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 7 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
7 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 8 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
8 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 10 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
10 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 12 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
12 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 15 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
15 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :

  • 20 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C13 Photo of IEC 60320 C13
  • NEMA 6-20P Photo of NEMA 6-20P
20 Feet
15 Amps
250 volts
IEC 60320 C13
NEMA 6-20P

1+ :

10+ :

100+ :



Specifications of NEMA 6-20P to IEC60320 C13 Power Cords

Current (Amps)
Voltage (Volts)
Connector (Female)
Plug (Male)
Cordage
Approvals
Certifications
Country of Origin
Color

NEMA 6-20P

NEMA 6-20P

General Info:

The NEMA 6-20P is a 3 Wire grounded plug featuring two line blades and a ground pin, rated up to 250V AC and 20A. The 6-20P has a horizontal and vertical blade to prevent attachment to lower ampere rated receptacles. However, the 6-20R (receptacle) offers a "T" slot allowing connection of both a 6-20P and a 6-15P. Common applications are commercial ovens and large air condition units. The NEMA 6-20P Series does not feature a neutral conductor.

What does the 6-20P Connect to?





NEMA 6-20R
NEMA 6-20R
The NEMA 6-20P Connects to both the NEMA 6-20R Connector and the NEMA 6-15/20R Wall Outlet. The Connector is used for extension cords and power drops, while the outlet is found in some commercial and industrial buildings.

IEC 60320 C13 CONNECTOR (FEMALE)

IEC 60320 C13 CONNECTOR (FEMALE)

General Information:

The IEC 60320 C13 is a grounded 3 Wire connector rated up to 250V and 15 Amps. The C13 mates with a C14 inlet, and is commonly used in a jumper cable scenario in IT Installations providing power from a PDU to a server, router, switch or other computing device. Most people know the C13 as 'the thing that plugs into my computer' because it is the standard connector used to power most desktop computers. In a desktop computer application, the most common cable is the NEMA 5-15P to C13, which connects your standard North American wall outlet to a desktop computer. The iec 320 c13 c14 plug and connector are synonymous with Information Technology equipment primarily, but the C13 can be found powering equipment like medical devices and gaming consoles.

What does the IEC 60320 C13 Connect to?





IEC 60320 C14 Plug'

IEC 60320 C14 Inlet
The IEC 320 type C13 connector is designed to connect to the IEC 320 C14 plug and inlet. The C14 Plug is commonly found on power cords located in office, commercial or data center settings since the C13 inlet is usually only found in those environments. The C14 Inlet is commonly found on a variety of IT Equipment like monitors, switches, printers, power adapters, and more.

White Label Shipping

White Label Shipping

Are you a reseller looking for Blind or White Label Drop Shipping? We offer both! During checkout simply select "Blind Shipping", then either upload your own packing slip, or, upload your logo and part numbers into ours. You will receive automated tracking emails as soon as your order has been packed so you can keep your customer up to date in realtime. Blind drop shipping has never been easier.

Manufactured Under ISO: 9001

Manufactured Under ISO: 9001

Our power cord sets are manufactured under an ISO 9001 quality management system to ensure that you get the same outstanding quality with on every order you place.
All of our NorthAmerican use Power Cord Sets are UL listed under E503529. This means that you can be sure that all of our power cord sets are of the highest quality and are certified for use in the United States.

UL Listed : E503526

UL Listed : E503526

World Cord Sets strives to deliver the best quality products for the lowest cost, to show our commitment to quality and our understanding of customers expectation for consistence of quality we obtained the UL certification. All of our North American use Power Cord Sets are UL listed under E503529. This means that you can be sure that all of our power cord sets are of the highest quality and are certified for use in the United States.

Lifetime Warranty

Lifetime Warranty

Why do we offer a lifetime warranty?

We offer a lifetime warranty because we know that it won't have to be used. Our products are manufactured using only the highest quality components, and, undergo rigorous quality assurance inspections and testing to ensure all of our products meet our exacting standards. Our lifetime warranty gives you peace of mind that your purchase is 100% guaranteed to work.


What does the warranty cover?

All cords, cables, patch panels, and adapters sold on this website in original unmodified condition are covered under this warranty. Warranty does not cover damage caused by misuse.


How does the warranty work?

To use the lifetime warranty, simply request an RMA and send your defective material back to us and we will either repair or replace the goods and return them back to you in working condition.

Documents & Drawings
