NEMA 6-20P to C15 15A 250V BLACK Power Cords

NEMA 6-20P to C15 15A 250V BLACK Power Cords
NEMA 6-20P to C15 15A 250V BLACK Power Cords
NEMA 6-20P to C15 15A 250V BLACK Power Cords

NEMA 6-20P to C15 15A 250V BLACK Power Cords



NEMA 6-20P to C15 15A 250V BLACK Power Cords

NEMA 6-20P

The NEMA 6-20P is a 3 Wire grounded plug featuring two blades and one ground pin rated up to 250V AC and 20 Amps. The NEMA 6-20P has one horizontal blade and one vertical blade and mates with a 6-20R Outlet.






Order online by clicking a product below, or, call us at (860) 763-2100 or email sales@worldcordsets.com


Part Number
Length
Current (Amps)
Voltage (Volts)
Connector (Female)
Plug (Male)
Availability
1+
10+
100+
  • 10 Feet
  • 15 Amps
  • 250 volts
  • IEC 60320 C15
  • NEMA 6-20P
10 Feet
15 Amps
250 volts
IEC 60320 C15
NEMA 6-20P


  • Product Information
  • Documents & Downloads
  • Submit a Request
  • Q & A

Need help? Ask the experts!

With over 30 years of experience in the power and data industry, we have the expertise to help you find exactly what you are looking for. We're more than just an online store, we have experts in the power and data industry that can help you online, over the phone, or via email.


  • Have a request from a customer and not sure what you need? Let us quote it for you!

  • Looking for a specific product and can't find it? Let us find it for you!

  • Need a question answered quickly? Live Chat with us!


860.763.2100 or Ask us a Question


Product Warranty

At WoCo, we are committed to providing you with quality products, and that is backed up by our 1 Year product warranty. If there are any defects due to workmanship, World Cord Sets will accept liability for the purchase price of the goods and associated freight charges to provide a full refund to the customer.


Committment to Quality

Providing high quality, affordable products and solutions is a cornerstone of what we do at World Cord Sets. All products we sell have passed our internal quality assurance standards. Most products sold (unless otherwise noted) pass industry standard certifications such such as RoHS, REACH, CE, UL, cUL, and many other international standards. You can find the list of standards and approvals for a product in the specifications section.


NEMA 6-20P

The NEMA 6-20P is a 3 Wire grounded plug featuring two blades and a ground pin, rated up to 250V AC and 20A. The 6-20P has a horizontal and vertical blade to prevent attachment to lower ampere rated receptacles. However, the 6-20R (receptacle) offers a "T" slot allowing connection of both a 6-20P and a 6-15P. Common applications are commercial ovens and large air condition units.

IEC 60320 C15 CONNECTOR (FEMALE)

The IEC 60320 C15 is a grounded 3 Wire connector rated up to  250V & 10 Amps Internationally and 125V/250V & 15 Amps in North America. The C15 mates with a C16 inlet as well as a C14 Inlet and is commonly used in IT Installations providing power from a PDU to a server, router, switch or other computing device. The C15 is a HIGH TEMPERATURE connector rated up to 120°C, unlike the 70°C rating of the C13. The C15 is commonly used in in electric kettles and other household appliances that involve higher temperatures than a normal C13 is made to withstand. The C15 connector is commonly used with 18awg SJT(OW), 16awg SJT(OW), and 14awg SJT(OW).
